The claw is adjustable in multiple stages, suitable for lifting heavy loads of different heights.
The pump and jack are separated, ensuring safety and flexibility, and enabling remote operation.
The cylinder can rotate 360°, allowing wide-range multi-directional operation.
Built-in return spring enables automatic retraction without load, making operation easier.
The claw features an anti-slip pattern and can tilt within ±6° for stable lifting.
Reinforced ribbed base design enhances strength and durability.
Made of alloy steel, featuring light weight and high load capacity, ideal for frequent relocation in hoisting and lifting operations.
The jack can also be used for lateral pushing; swivel hose connectors allow flexible connection from any direction.
| ITEM | UNIT | HMSA-10S | HMSA-16S | HMSA-20S | HMSA-26S |
| Claw Load Capacity | Ton | 10 tons | 16 tons | 20 tons | 26 tons |
| Minimum Claw Height | mm | 15 | 20 | 22 | 23 |
| Stroke | mm | 107 | 110 | 112 | 115 |
| Maximum Claw Height | mm | 286 | 314 | 338 | 350 |
| Claw Height Adjustable | mm | 45+41×4 | 48+46×4 | 52+51×4 | 54+52×4 |
| Minimum Top Height | mm | 265 | 292 | 320 | 330 |
| Maximum Top Height | mm | 373 | 402 | 432 | 445 |
| Base Dimensions (L × W) | mm | 205×200 | 228×210 | 250×245 | 268×258 |
| Oil Capacity | L | 210cm³ | 242cm³ | 316cm³ | 418cm³ |
| Net Weight | kg | 20.5 | 26.5 | 38.5 | 45.5 |
