| Item | Unit | Design Value | |
| Rated Lifting Capacity | kg | 3500 | |
| Total length | No forks | mm | 2680 |
| Forklift | mm | 3980 | |
| Full width | Wheel width | mm | 1220 |
| Frame width | mm | 1300 | |
| Overall Height | Non-Lifting Mast Height | mm | 2150 |
| Guardrail Height | mm | 2150 | |
| Maximum Working Height | mm | 4150 | |
| Wheelbase | mm | 1800 | |
| Front overhang | mm | 300 | |
| Front track width | mm | 1020 | |
| Rear track width | mm | 1000 | |
| Minimum ground clearance | mm | 110 | |
| Maximum lifting height (unloaded) | mm | 3000 | |
| Free lift height | mm | 200 | |
| Mast tilt angle (front/rear) | (°) | 6/12 | |
| Overall machine weight (standard unloaded) | kg | 4200 | |
| Maximum lifting speed (unloaded) | mm/s | 230 | |
| Maximum lifting speed (loaded) | mm/s | 200 | |
| Minimum turning radius | mm | 2300 | |
| Maximum Travel Speed (Unloaded) | km/h | 12 | |
| Maximum Travel Speed (Loaded) | km/h | 10 | |
| Maximum Gradeability (Loaded) | % | 12 | |
| Maximum Hook Pulling Force (Loaded) | kn | 5 | |
| Front Wheel Specifications | / | 28*9-15 | |
| Rear Wheel Specifications | / | 18*9-7 | |
| Lifting Motor Power | KW | 10 | |
| Drive Motor Power | KW | 11.5 | |
| Load Center Distance | mm | 500 | |
| Charger Input Voltage | V | 220 | |
| Charging Time | h | 8-10 | |
| Battery Capacity | ah | 230 | |
| Rated Voltage | V | 80 | |
