Specially designed to suit standard ANSI B16.5/BS1560 flanges.
Single-acting (spring return) or double-acting cylinder.
Tri-blade technology provides three cutting surfaces on a single blade.
Interchangeable heads provide maximum nut range flexibility.
Preset scale allows controlled blade extension, which avoids damage to bolt threads.
Grip tape and handle included for more secure manoeuvrability.
Nickel-plated cylinder body for excellent corrosion protection and improved durability in harsh environments.
Internal Pressure Relief Valve for overload protection.
Bolt Range (mm) | Hexagon Nut Rang9 | Capacity ton(kN) | Oil Capacity (cm³) | Model Number | Dimensions(mm) | Weight (kg) | Hydraulic Cylinder | Cutting Head | Replace- ment Blade | ||||||
A | B | C | D | E | F | G | |||||||||
M45-M52 | 70-80 | 103(917) | 377 | NS-7080 | 132 | 28 | 180 | 8.0 | 81 | 186 | 412 | 37.0 | NSC-70 | NSH-7080 | NSB-70 |
M45-M56 | 70-85 | 103(917) | 377 | NS-7085 | 145 | 30 | 180 | 8.0 | 81 | 196 | 422 | 37.0 | NSC-70 | NSH-7085 | NSB-70 |
M45-M64 | 70-95 | 103(917) | 377 | NS-7095 | 160 | 32 | 180 | 8.0 | 81 | 201 | 432 | 38.5 | NSC-70 | NSH-7095 | NSB-70 |
M45-M72 | 70-105 | 103(917) | 377 | NS-70105 | 174 | 35 | 180 | 9.0 | 81 | 209 | 443 | 39.5 | NSC-70 | NSH-70105 | NSB-70 |
M76-M80 | 110-115 | 193(1711) | 819 | NS-110115 | 189 | 36 | 234 | 3.7 | 111 | 234 | 472 | 69.0 | NSC-110 | NSH-110115 | NSB-110 |
M76-M90 | 110-130 | 193(1711) | 819 | NS-110130 | 219 | 41 | 234 | 2.5 | 111 | 242 | 493 | 71.5 | NSC-110 | NSH-110130 | NSB-110 |
Bolt Range (mm) | Hexagon Nut (mm) | Capacity ton(kN) | Oil Capacity (cm³) | Model Number | Dimensions (mm) | Weight (kg) | Replacement Chisel Model Number | ||||||
A | B | C | D | F | H | J | |||||||
M6-M12 | 10-19 | 5(49) | 15 | NC-1319 | 40 | 170 | 7 | 19 | 28 | 48 | 21 | 1.2 | NCB-1319 |
M12-M16 | 19-24 | 10(98) | 20 | NC-1924* | 54 | 191 | 10 | 26 | 40 | 62 | 25 | 2.0 | NCB-1924 |
M16-M22 | 24-32 | 15(147) | 60 | NC-2432* | 64 | 222 | 13 | 29 | 51 | 72 | 33 | 3.0 | NCB-2432 |
M22-M27 | 32-41 | 20(196) | 80 | NC-3241* | 75 | 244 | 17 | 36 | 66 | 88 | 43 | 4.4 | NCB-3241 |
M27-M33 | 41-50 | 35(343) | 155 | NC-4150 | 94 | 288 | 21 | 45 | 74 | 105 | 54 | 8.2 | NCB-4150 |
M33-M39 | 50-60 | 50(490) | 240 | NC-5060 | 106 | 318 | 23 | 54 | 90 | 128 | 60 | 11.8 | NCB-5060 |
M39-M48 | 60-75 | 90(882) | 492 | NC-6075 | 156 | 393 | 26 | 72 | 110 | 181 | 80 | 34.1 | NCB-6075 |
